UCC2895PWTRG4

UCC2895PWTRG4, phase-shift PWM controller, TSSOP, 17V, 650mW, 15mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2000 ~ 2000 :	5.00 / Piece

PartNumber:: UCC2895PWTRG4

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-28

From Other Seller

Part Number:UCC2895PWTRG4
US $5.00 - 5.00
Quantity:

piece

Product Summary

The UCC2895PWTRG4 is a phase-shift PWM controller that implements control of a full-bridge power stage by phase shifting the switching of one half-bridge with respect to the other. It allows constant frequency pulse-width modulation in conjunction with resonant zero-voltage switching to provide high efficiency at high frequencies. The part can be used either as a voltage-mode or current-mode controller. The applications of the UCC2895PWTRG4 include Phase-Shifted Full-Bridge Converters, Off-Line, Telecom, Datacom and Servers, Distributed Power Architecture and High-Density Power Modules. It operates with dramatically less supply current than it is bipolar counterparts. The UCC2895PWTRG4 can operate with a maximum clock frequency of 1 MHz.

Parametrics

UCC2895PWTRG4 absolute maximum ratings: (1)Supply voltage (IDD < 10 mA): 17 V; (2)Supply current: 30mA; (3)Reference current: 15 mA; (4)Output crrent: 100mA; (5)Analog inputs EAP, EAN, EAOUT, RAMP, SYNC, ADS, CS, SS/DISB --0.3 V to REF+0.3 V; (6)Drive outputs OUTA, OUTB, OUTC, OUTD: -0.3 V to VCC + 0.3 V; (7)Power dissipation at TA= 25℃: 650 mW; (8)Storage temperature range, Tstg: -65 to 150℃; (9)Junction temperature range, TJ: -55 to 150℃; (10)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 300℃.

Features

UCC2895PWTRG4 features: (1)Programmable Output Turn-on Delay; (2)Adaptive Delay Set; (3)Bidirectional Oscillator Synchronization; (4)Voltage-Mode, Peak Current-Mode, or Average Current-Mode Control; (5)Programmable Softstart/Softstop and Chip Disable via a Single Pin; (6)0% to 100% Duty-Cycle Control; (7)7MHz Error Amplifier; (8)Operation to 1 MHz; (9)Typical 5-mA Operating Current at 500 kHz; (10)Very Low 150-μA Current During UVLO.
