AT24C01

AT24C01, 2-Wire Serial EEPROM, DIP, 6.25V, 5.0mA, -1.0V to +7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~6.00

PartNumber:: AT24C01

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. elaine's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-02

From Other Seller

Part Number:AT24C01
US $0.01 - 6.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C01 is a 2-Wire Serial EEPROM. It provides 1024 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 128 words of 8 bits each. The AT24C01 is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. The AT24C01 is available in space saving 8-pin PDIP, 8-pin MSOP, 8-pin TSSOP, and 8-pin JEDEC SOIC packages and is accessed via a 2-wire serial interface. In addition, the entire family is available in 5.0V (4.5V to 5.5V), 2.7V (2.7V to 5.5V), 2.5V (2.5V to 5.5V) and 1.8V (1.8V to 5.5V) versions.

Parametrics

AT24C01 absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -1.0V to +7.0V; (4) Maximum Operating Voltage: 6.25V; (5) DC Output Current: 5.0mA.

Features

AT24C01 features: (1)Low Voltage and Standard Voltage Operation: 5.0 (VCC = 4.5V to 5.5V), 2.7 (VCC = 2.7V to 5.5V), 2.5 (VCC = 2.5V to 5.5V), 1.8 (VCC = 1.8V to 5.5V); (2)Internally Organized 128 x 8; (3)2-Wire Serial Interface; (4)Bidirectional Data Transfer Protocol; (5)100 kHz (1.8V, 2.5V, 2.7V) and 400 kHz (5V) Compatibility; (6)4-Byte Page Write Mode; (7)Self-Timed Write Cycle (10 ms max); (8)High Reliability; (9)Endurance: 1 Million Write Cycles; (10)Data Retention: 100 Years; (11)ESD Protection: >3000V; (12)Automotive Grade and Extended Temperature Devices Available; (13)8-Pin PDIP, 8-Pin MSOP, 8-Pin TSSOP and 8-Pin JEDEC SOIC Packages.
