TPS79801QDGNRQ1

TPS79801QDGNRQ1, 50V, high-voltage micropower low-dropout (LDO) linear regulator, 50mA, 1uF

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.00~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 1000 :	6.00 / Piece

PartNumber:: TPS79801QDGNRQ1

Brand:: Texas Instruments - TI | Pack: MSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-25

From Other Seller

Part Number:TPS79801QDGNRQ1
US $6.00 - 6.00
Quantity:

piece

Product Summary

The TPS79801QDGNRQ1 is a line of 50V high-voltage micropower low-dropout (LDO) linear regulator. The TPS79801QDGNRQ1 is capable of supplying 50-mA output current with a dropout voltage of only 300 mV. Designed for low quiescent current high voltage (50 V) applications, 40μA operating and 1μA in shutdown makes the TPS79801QDGNRQ1 an ideal choice for battery-powered or high-voltage systems. Quiescent current is also well-controlled in dropout. The applications of the TPS79801QDGNRQ1 include Low-Current, High-Voltage Regulators, and Regulators for Battery-Powered Systems, Telecom, and Automotive.

Parametrics

TPS79801QDGNRQ1 absolute maximum ratings: (1)IN(2): –65 V to 60 V; (2)OUT: –0.3 V to 28 V; (3)VIN Input voltage range FB: –0.3 V to 7 V; (4)EN(2): –65 V to 60 V; (5)Enable to IN differential: 0.6 V＜VIN; (6)JEDEC 51-5(3): 60℃/W; (7)θJA Thermal impedance, junction to free air JEDEC 51-7(4): 130℃/W; (8)TJ Junction temperature range(5): –40℃ to 125℃; (9)TSTG Storage temperature range: –65 to 150℃; (10)Human-Body Model (HBM): 2000V; (11)ESD rating; (12)Charged-Device Model (CDM): 1000V.

Features

TPS79801QDGNRQ1 features: (1)Qualified for Automotive Applications ; (2)Wide Input Voltage Range: 3 V to 50 V; (3)Low Quiescent Current: 40μA (Typ); (4)Low Dropout Voltage: 300 mV (Typ); (5)Output Current: 50 mA; (6)No Input Protection Diodes Needed; (7)Adjustable Output From 1.275 V to 28 V; (8)1μA Quiescent Current in Shutdown; (9)Stable With 1μF Output Capacitor; (10)Stable With Aluminum, Tantalum, or Ceramic Capacitors; (11)Reverse Input-Battery Protection; (12)Reverse Output Current Flow Protection; (13)Thermal Limiting; (14)Available in MSOP-8 Package.
