TLC5944RHBT

TLC5944RHBT, 16-channel, constant current sink driver, QFN, -0.3V to +6.0V, 500V, 60mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2000 ~ 2000 :	2.00 / Piece

PartNumber:: TLC5944RHBT

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:TLC5944RHBT
US $2.00 - 2.00
Quantity:

piece

Product Summary

The TLC5944RHBT is a 16-channel, constant current sink driver. Each channel is individually adjustable with 4096 pulse-width modulated (PWM) steps and 64 constant sink current (dot correction) steps. The dot correction (DC) adjusts for brightness variations between LEDs. Both grayscale (GS) control and DC are accessible via a common serial interface port. The maximum current value of all 16 channels can be set by a single external resistor. The applications of the TLC5944RHBT include Monochrome, Multicolor, Full-Color LED Displays Using Multiplexing System, LED Signboards Using Multiplexing System.

Parametrics

TLC5944RHBT absolute maximum ratings: (1)VCC Supply voltage, VCC: –0.3 to +6.0 V; (2)VUP Pre-charge voltage: –0.3 to +16 V; (3)XERR: 6mA; (4)IOUT Output current (dc) OUT0 to OUT15: 70mA; (5)VIN: LANK, GSCLK, DCSEL, IREF: –0.3 to VCC + 0.3 V; (6)SOUT, XERR: –0.3 to VCC + 0.3 V; (7)VOUT Output voltage range OUT0 to OUT15: –0.3 to VUP + 0.3 V; (8)TJ(max) Operating junction temperature: +150℃; (9)TSTG Storage temperature range: –55 to +150℃; (10)Human body model (HBM): 2 kV; (11)ESD rating Charged device model (CDM): 500V.

Features

TLC5944RHBT features: (1)16 Channels, Constant Current Sink Output; (2)Thermal Shutdown (TSD):; (3)60-mA Capability (constant current sink); (4)12-Bit (4096 Steps) Grayscale Control with PWM; (5)6-Bit (64 Steps) Dot Correction with Sink Current; (6)Pre-Thermal Warning (PTW); (7)Internal Pre-Charge FET to Prevent LED Ghosting Phenomenon on Multiplexed LED Systems ; (8)Readable Error Information; (9)LED Power-Supply Voltage up to 15 V; (10)VCC = 3.0 V to 5.5 V; (11)Noise Reduction; (12)Constant Current Accuracy; (13)CMOS Logic Level I/O; (14)30-MHz Data Transfer Rate; (15)33-MHz Grayscale Control Clock.
