PCA9534APW

PCA9534APW, 16-pin CMOS device, TSSOP, -0.5V to 6.0V, 20mA, 200mW, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2000 ~ 2000 :	2.00 / Piece

PartNumber:: PCA9534APW

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:PCA9534APW
US $2.00 - 2.00
Quantity:

piece

Product Summary

The PCA9534APW is a 16-pin CMOS device that provides 8 bits of General Purpose parallel Input/Output (GPIO) expansion for I2C-bus/SMBus applications and was developed to enhance the NXP Semiconductors family of I2C-bus I/O expanders. The improvements of PCA9534APW include higher drive capability, 5 V I/O tolerance, lower supply current, individual I/O configuration, 400 kHz clock frequency, and smaller packaging. I/O expanders provide a simple solution when additional I/O is needed for ACPI power switches, sensors, push buttons, LEDs, fans, etc.

Parametrics

PCA9534APW absolute maximum ratings: (1)supply voltage: -0.5 to +6.0 V; (2)input current: ±20 mA; (3)voltage on an input/output pin VSS: - 0.5 to 5.5 V; (4)output current on pin IOn: ±50 mA; (5)supply current: 85 mA; (6)ground supply current: 100 mA; (7)total power dissipation: 200 mW; (8)storage temperature: -65 to +150 ℃; (9)ambient temperature: -40 to +85 ℃.

Features

PCA9534APW features: (1)8-bit I2C-bus GPIO; (2)Operating power supply voltage range of 2.3 V to 5.5 V; (3)5 V tolerant I/Os; (4)Polarity Inversion register; (5)Active LOW interrupt output; (6)Low standby current; (7)Noise filter on SCL/SDA inputs; (8)No glitch on power-up; (9)Internal power-on reset.
