Product Summary

The ISS355 is a high-speed switching diode fabricated in planar technology, and encapsulated in hermetically sealed leaded glass SOD27 (DO-35) packages.

Parametrics

ISS355 absolute maximum ratings: (1)VRRM repetitive peak reverse voltage: 75V; (2)VR continuous reverse voltage: 75V; (3)IF continuous forward current: 200mA; (4)IFRM repetitive peak forward current: 450mA; (5)IFSM non-repetitive peak forward current square wave; Tj = 25℃ prior to surge; t = 1μs: 4A, t = 1ms: 1A, t = 1s: 0.5A; (6)Ptot total power dissipation Tamb = 25℃; note 1: 500mW; (7)Tstg storage temperature: -65 to +200℃; (8)Tj junction temperature: 200℃.

Features

ISS355 features: (1) Hermetically sealed leaded glass SOD27 (DO-35) package; (2) High switching speed: max. 4ns; (3) General application; (4) Continuous reverse voltage: max. 75V; (5) Repetitive peak reverse voltage: max. 75V; (6) Repetitive peak forward current: max. 450mA.

Diagrams

ISS355 block diagram
