ADM706TARZ-REEL

ADM706TARZ-REEL, microprocessor supervisory circuit, SOP, 20mA, 470mW, –0.3V to +6V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.85~1.85 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 100 :	1.85 / Piece

PartNumber:: ADM706TARZ-REEL

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-22

From Other Seller

Part Number:ADM706TARZ-REEL
US $1.85 - 1.85
Quantity:

piece

Product Summary

The ADM706TARZ-REEL is a microprocessor supervisory circuit. The ADM706TARZ-REEL is suitable for monitoring either 3 V or 3.3 V power supplies. The applications of ADM706TARZ-REEL are Microprocessor Systems, Computers, Controllers, Intelligent Instruments, Critical uP Monitoring, Automotive Systems, Battery Operated Systems, and Portable Instruments.

Parametrics

ADM706TARZ-REEL absolute maximum ratings: (1)VCC:–0.3 V to +6 V; (2)All Other Inputs:–0.3 V to VCC + 0.3 V; (3)Input Current: VCC:20 mA, GND:20 mA; (4)Digital Output Current:20 mA; (5)Power Dissipation:470 mW, θJA Thermal Impedance:110℃/W; (6)Operating Temperature Range Industrial (A Version):–40℃ to +85℃; (7)Lead Temperature (Soldering, 10 secs):+300℃; (8)Vapor Phase (60 secs):+215℃; (9)Infrared (15 secs):+220℃; (10)Storage Temperature Range:–65℃ to +150℃; (11)ESD Rating:>5 kV.

Features

ADM706TARZ-REEL features: (1)Precision Supply-Voltage Monitor +2.93 V; (2)100μA Quiescent Current; (3)200 ms Reset Pulse width; (4)Debounced Manual Reset Input (MR); (5)Independent Watchdog Timer—1.6 sec Timeout; (6)Reset Output; (7)Active Low; (8)Both Active High and Active Low; (9)Voltage Monitor for Power-Fail or Low Battery Warning; (10)Guaranteed RESET Valid with VCC = 1 V; (11)Superior Upgrade for MAX706P/R/S/T, MAX708R/S/T.
