Product Summary

The TPS650245RHBR is an integrated power management IC for applications powered by one Li-con or Li-polymer cell, which require multiple power rails. The TPS650245RHBR provides three highly efficient, step-down converters targeted at providing the core voltage, peripheral. I/O and memory rails in a processor based system. All three step-down converters enter a low power mode at light load for maximum efficiency across the widest possible range of load currents. The TPS650245RHBR can be forced into fixed frequency PWM mode by pulling the MODE pin high. The applications of the TPS650245RHBR include PDA, Cellular/Smart Phone, GPS, Digital Still Camera, Split Supply DSP and uP Solutions, Samsung ARM-Based Processors, etc.

Parametrics

TPS650245RHBR absolute maximum ratings: (1)Input voltage range on all pins except A/PGND pins with respect to AGND: –0.3 to 7V; (2)Current at VINDCDC1, L1, PGND1, VINDCDC2, L2, PGND2, VINDCDC3, L3, PGND3: 2000mA; (3)Peak current at all other pins: 1000mA; (4)Continuous total power dissipation See Dissipation Rating Table; (5)TA Operating free-air temperature: –40 to 85℃; (6)TJ Maximum junction temperature: 125℃; (7)Tst Storage temperature: –65 to 150℃; (8)Lead temperature 1,6 mm (1/16-inch) from case for 10 seconds: 260℃.

Features

TPS650245RHBR features: (1)1.6A, 1.0A or 0.8A, 97% Efficient Step-Down Converter for System Voltage (VDCDC1); (2)1.6A, 1.0A or 0.8A, up to 95% Efficient Step-Down Converter for Memory Voltage (VDCDC2); (3)0.8A, 90% Efficient Step-Down Converter for Processor Core (VDCDC3); (4)Two Selectable Voltages for VDCDC3; (5)30mA LDO for Vdd_alive; (6)2×220)mA General Purpose LDOs (LDO1 and LDO2); (7)Dynamic Voltage Management for Processor Core; (8)LDO1 and LDO2 Voltage Externally Adjustable; (9)Separate Enable Pins for Inductive Converters; (10)2.25MHz Switching Frequency; (11)85mA Quiescent Current.
