TPS62560DRVR

TPS62560DRVR, efficient synchronous step-down dc-dc converter, QFN, -0.3V to 7V, 200V, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 1000 :	3.00 / Piece

PartNumber:: TPS62560DRVR

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-25

From Other Seller

Part Number:TPS62560DRVR
US $3.00 - 3.00
Quantity:

piece

Product Summary

The TPS62560DRVR is an efficient synchronous step-down dc-dc converter optimized for battery-powered applications. The TPS62560DRVR provides up to 600mA output current from a single Li-Ion cell and are ideal to power mobile phones and other portable applications. The applications of the TPS62560DRVR include PDAs, Pocket PCs, Portable Media Players, Low-Power DSP Supply, POL Applications.

Parametrics

TPS62560DRVR absolute maximum ratings: (1)Input voltage range(2): –0.3 to 7V; (2)Voltage range at EN, MODE –0.3 to VIN +0.3, ≤7V; (3)Voltage on SW:–0.3 to 7V; (4)Peak output current: Internally limited A; (5)HBM human-body model: 2kV; (6)ESD rating(3) CDM charged-device model: 1kV; (7)Machine model: 200 V; (8)TJ Maximum operating junction temperature –40 to 125℃; (9)Tstg Storage temperature range –65 to 150℃.

Features

TPS62560DRVR features: (1)High-Efficiency Step-Down Converter; (2)Output Current up to 600mA; (3)Wide VIN Range from 2.5V to 5.5V for Li-Ion Batteries With Extended Voltage Range; (4)Adjustable and Fixed Output-Voltage Options; (5)2.25-MHz Fixed-Frequency Operation; (6)Power-Save Mode at Light Load Currents; (7)Output Voltage Accuracy in PWM Mode ±2.5%; (8)Typical 15μA Quiescent Current; (9)100% Duty Cycle for Lowest Dropout; (10)Soft Start; (11)Voltage Positioning at Light Loads; (12)Available in a Small TSOT, and 2mm × 2mm × 0,8mm SON Package ; (13)Allows ＜1mm Solution Height.
