SN75LBC174A16DW

SN75LBC174A16DW, quadruple differential line driver, SOP, -0.3V to 6V, 13kV, 100Ω

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.30~3.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2000 ~ 2000 :	3.30 / Piece

PartNumber:: SN75LBC174A16DW

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-22

From Other Seller

Part Number:SN75LBC174A16DW
US $3.30 - 3.30
Quantity:

piece

Product Summary

The SN75LBC174A16DW is a quadruple differential line driver with 3-state outputs, designed for TIA/EIA-485 (RS-485), TIA/EIA-422 (RS-422), and ISO 8482 applications. The SN75LBC174A16DW is optimized for balanced multipoint bus transmission at signalling rates up to 30 million bitsper second. The transmission media may be printed-circuit board traces, backplanes, or cables. The ultimate rate and distance of data transfer is dependent upon the attenuation characteristics of the media and the noise coupling to the environment.

Parametrics

SN75LBC174A16DW absolute maximum ratings: (1)Supply voltage range, VCC (see Note 1): -0.3 V to 6 V; (2)Voltage range at any bus (DC): -10 V to 15 V; (3)Voltage range at any bus (transient pulse through 100Ω, see Figure 8): -30 V to 30 V; (4)Input voltage range at any A or EN terminal, VI: -0.5 V to VCC + 0.5V; (5)Electrostatic discharge: Human body model (see Note 2) Y, Z, and GND: 13kV; (6)All pins: 5kV; (7)Charged-device model (see Note 3) All pins: 1 kV; (8)Storage temperature range, Tstg: -65℃ to 150℃; (9)Continuous power dissipation: See Dissipation Rating Table; (10)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

SN75LBC174A16DW features: (1)Designed for TIA/EIA-485, TIA/EIA-422 and ISO 8482 Applications; (2)Signaling Rates up to 30 Mbps; (3)Propagation Delay Times ＜ 11 ns; (4)Low Standby Power Consumption 1.5 mA Max; (5)Output ESD Protection Exceeds 13 kV; (6)Driver Positive- and Negative-Current Limiting; (7)Power-Up and Power-Down Glitch-Free for Line Insertion Applications; (8)Thermal Shutdown Protection; (9)Industry Standard Pin-Out, Compatible With SN75174, MC3487, DS96174, LTC487, and MAX3042.
