PCI4510AZHK

PCI4510AZHK, integrated single-socket PC Card controller, BGA, 3.3V, 5V, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $15.00~15.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 1000 :	15.00 / Piece

PartNumber:: PCI4510AZHK

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-28

From Other Seller

Part Number:PCI4510AZHK
US $15.00 - 15.00
Quantity:

piece

Product Summary

The PCI4510AZHK is an integrated single-socket PC Card controller with an IEEE 1394 open host controller link-layer controller (LLC) and two-port 1394 PHY. This high performance integrated solution provides the latest in both PC Card and IEEE 1394 technology. The PCI4510AZHK is compliant with PCI Local Bus Specification. Function 0 provides the independent PC Card socket controller compliant with the latest PC Card Standards. The PCI4510AZHK provides features that make it the best choice for bridging between the PCI bus and PC Cards, and supports either 16-bit or CardBus PC Cards in the socket, powered at 5 V or 3.3 V, as required.

Features

PCI4510AZHK features: (1)PC Card Standard 8.0 compliant; (2)PCI Bus Power Management Interface Specification 1.1 compliant; (3)Advanced Configuration and Power Interface Specification 2.0 compliant; (4)PCI Local Bus Specification Revision 2.2 compliant; (5)PC 98/99 and PC2001 compliant; (6)Compliant with the PCI Bus Interface Specification for PCI-to-CardBus Bridges; (7)1.8-V core logic and 3.3-V I/O cells with internal voltage regulator to generate 1.8-V core VCC; (8)Universal PCI interfaces compatible with 3.3-V and 5-V PCI signaling environments; (9)Physical write posting of up to three; (10)Provides VGA/palette memory and I/O, and subtractive decoding options, LED activity terminals; (11)Node power class information signaling for system power management.
