MAX306EQI+T

CMOS analog multiplexer, +4.5V to +30V, 28SOIC, 7Ω, MAX306EQI+T

Rated 5 Rating 5 | reviews | Write a review

Price:: US $10.80~10.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
500 ~ 500 :	10.80 / Piece

PartNumber:: MAX306EQI+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-21

From Other Seller

Part Number:MAX306EQI+T
US $10.80 - 10.80
Quantity:

piece

Product Summary

The MAX306EQI+T is a precision, monolithic, CMOS analog multiplexer (mux). It offers low on-resistance (less than 100Ω), which is matched to within 5Ω between channels and remains flat over the specified analog signal range (7Ω, max). The MAX306EQI+T also offers low leakage over temperature (INO(OFF) less than 2.5nA at +85℃) and fast switching speeds (tTRANS less than 250ns). The device is a single-ended 1-of-16 device. The MAX306EQI+T is fabricated with the improved 44V silicon-gate process. Design improvements yield extremely low charge injection (less than 10pC) and guarantee electrostatic discharge (ESD) protection greater than 2000V. Applications of the MAX306EQI+T are: (1)Sample-and-Hold Circuits; (2)Test Equipment; (3)Heads-Up Displays; (4)Guidance and Control Systems; (5)Military Radios; (6)Communications Systems; (7)Battery-Operated Systems PBX, PABX; (8)Audio Signal Routing.

Parametrics

MAX306EQI+T absolute maximum ratings: (1)Continuous Current (any terminal): 30mA; (2)Peak Current, NO or COM: 100mA; (3)Continuous Power Dissipation: 727mW; (4)Operating Temperature Ranges: -40℃ to +85℃; (5)Storage Temperature Range: -65℃ to +150℃; (6)Lead Temperature (soldering, 10s): +300℃.

Features

MAX306EQI+T features: (1)Guaranteed Charge Injection, <10pC; (2)INO(OFF) Leakage <2.5nA at +85℃; (3)ICOM(OFF) Leakage <20nA at +85℃; (4)ESD Protection >2000V; (5)Plug-In Upgrade for Industry-Standard DG406/DG407/DG506A/DG507A; (6)Single-Supply Operation (+4.5V to +30V), Bipolar-Supply Operation (±4.5V to ±30V); (7)Low Power Consumption, <1.25mW; (8)Rail-to-Rail Signal Handling; (9)TTL/CMOS-Logic Compatible.
