ISL6522CBZ-T

ISL6522CBZ-T, Buck and Synchronous Rectifier, PWM Controller, SOP, 15V, GND -0.3V to VCC +0.3V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.60~1.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2500 ~ 2500 :	1.60 / Piece

PartNumber:: ISL6522CBZ-T

Brand:: Intersil Corporation - Intersil | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-17

From Other Seller

Part Number:ISL6522CBZ-T
US $1.60 - 1.60
Quantity:

piece

Product Summary

The ISL6522CBZ-T is a Buck and Synchronous Rectifier, Pulse-Width Modulator (PWM) Controller. The ISL6522CBZ-T provides complete control and protection for a DC-DC converter optimized for high-performance microprocessor applications. It is designed to drive two N-Channel MOSFETs in a synchronous rectified buck topology. The ISL6522CBZ-T integrates all of the control, output adjustment, and monitoring and protection functions into a single package. The applications of the ISL6522CBZ-T include Power supply for Pentium, Pentium Pro, PowerPC and AlphaPC microprocessors, High-power 5V to 3.xV DC-DC regulators, Low-voltage distributed power supplies.

Parametrics

ISL6522CBZ-T absolute maximum ratings: (1)Supply Voltage, VCC: +15.0V; (2)Boot Voltage, VBOOT-VPHASE: +15.0V; (3)Input, Output or I/O Voltage: GND -0.3V to VCC +0.3V; (4)ESD Classification: Class 2.

Features

ISL6522CBZ-T features: (1)Drives two N-Channel MOSFETs; (2)Operates from +5V or +12V input; (3)Simple single-loop control design: Voltage-mode PWM control; (4)Fast transient response; (5)Excellent output voltage regulation; (6)Over current fault monitor; (7)Converter can source and sink current; (8)Small converter size; (9)14-lead SOIC and TSSOP package and 16-lead 5x5mm QFN Package; (10)QFN Package: Compliant to JEDEC PUB95 MO-220 QFN-Quad Flat; (11)No Leads-Product Outline.; (12)Near Chip-Scale Package Footprint; Improves PCB Efficiency and Thinner in Profile; (13)Pb-Free Available (RoHS Compliant).
