Product Summary
The CD4060BM96 is a 14-Stage Ripple Carry Binary Counter. The CD4060BM96 is advanced one count on the negative transition of each clock pulse. The counters are reset to the zero state by a logical “1” at the reset input independent of clock.
Parametrics
CD4060BM96 absolute maximum ratings: (1)Supply Voltage (VDD): -0.5V to +18V; (2)Input Voltage (VIN): -0.5V to VDD +0.5V; (3)Storage Temperature Range (TS): -65℃ to +150℃; (4)Package Dissipation (PD) Dual-In-Line: 700mW; (5)Small Outline: 500mW; (6)Lead Temperature (TL) (Soldering, 10 seconds): 260℃.
Features
CD4060BM96 features: (1)Wide supply voltage range 1.0V to 15V; (2)High noise immunity 0.45 VDD (typ.); (3)Low power TTL Fan out of 2 driving 74L compatibility or 1 driving 74LS; (4)Medium speed operation 8 MHz typ. at VDD e 10V; (5)Schmitt trigger clock input.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CD4060BM96 |
Texas Instruments |
Counter ICs CMOS 14-St Ripple- Carry Binary |
Data Sheet |
|
|
||||||||||||
|
CD4060BM96E4 |
Texas Instruments |
Counter ICs CMOS 14-St Ripple- Carry Binary |
Data Sheet |
Negotiable |
|
||||||||||||
|
CD4060BM96G4 |
Texas Instruments |
Counter ICs CMOS 14-St Ripple- Carry Binary |
Data Sheet |
Negotiable |
|
||||||||||||
