Product Summary

The BSS84 is a P-channel enhancement mode field effect transistor.

Parametrics

BSS84 absolute maximum ratings: (1)VDSS, drain-source voltage: -50V; (2)VGSS, gate-source voltage: ±20V; (3)ID, drain current-continuous: -0.13A; pulsed: -0.52A; (4)PD, maximum power dissipation: 0.36W; Derate above 25℃: 2.9mW/℃; (5)TJ, TSTG, operating and storage junction temperature range: -55 to +150℃; (6)TL, maximum lead temperature for soldering purposes: 300℃.

Features

BSS84 features: (1)-0.13A, -50V, RDS=10Ω@VGS=-5V; (2)Voltage controlled p-channel small signal switch; (3)High density cell design for low RDS; (4)High saturation current.

Diagrams

BSS84 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BSS84
BSS84
Fairchild Semiconductor
MOSFET SOT-23 P-CH ENHANCE
Data Sheet
0-1: $0.17
1-25: $0.15
25-100: $0.09
100-250: $0.05
BSS84,215
BSS84,215
NXP Semiconductors
MOSFET P-CH DMOS 50V 130MA
Data Sheet
0-1: $0.04
1-25: $0.03
25-100: $0.03
100-250: $0.03
BSS84_D87Z
BSS84_D87Z
Fairchild Semiconductor
MOSFET P-Ch Spec Enhance Mode Field Effect
Data Sheet
Negotiable
BSS84-7-F
BSS84-7-F
Diodes Inc.
MOSFET -50V 250mW
Data Sheet
0-1: $0.25
1-10: $0.18
10-100: $0.08
100-500: $0.07
BSS84AKM,315
BSS84AKM,315
NXP Semiconductors
MOSFET P-CH -50 V -230 mA 50V 230mA
Data Sheet
0-6000: $0.06
6000-10000: $0.05
BSS84AKS,115
BSS84AKS,115
NXP Semiconductors
MOSFET P-CH -50 V -160 mA
Data Sheet
0-1: $0.23
1-25: $0.19
25-100: $0.15
100-250: $0.11
BSS84AKT,115
BSS84AKT,115
NXP Semiconductors
MOSFET P-CH -50 V -150 mA
Data Sheet
0-1: $0.20
1-25: $0.17
25-100: $0.13
100-250: $0.10
BSS84AKV,115
BSS84AKV,115
NXP Semiconductors
MOSFET P-CH -50 V -170 mA
Data Sheet
0-1: $0.20
1-25: $0.16
25-100: $0.13
100-250: $0.11
