Product Summary

The BAV99-7 is a dual surface mount switching diode.

Parametrics

BAV99-7 absolute maximum ratings: (1)Non-Repetitive Peak Reverse Voltage, VRM: 100 V; (2)Peak Repetitive Reverse Voltage, VRRM: 75V; (3)Working Peak Reverse Voltage, VRWM: 75V; (4)DC Blocking Voltage, VR: 75 V; (5)RMS Reverse Voltage, VR(RMS): 53 V; (6)Forward Continuous Current, IFM: 300mA; (7)Non-Repetitive Peak Forward Surge Current, IFSM: 2.0 A; (8)Power Dissipation, Pd: 350mW; (9)Thermal Resistance Junction to Ambient Air, RθJA: 357/W ; (10)Operating and Storage Temperature Range, Tj , TSTG: -65 to +150℃.

Features

BAV99-7 features: (1)Fast Switching Speed; (2)Surface Mount Package Ideally Suited for Automatic Insertion ; (3)For General Purpose Switching Applications; (4)High Conductance; (5)Lead Free/RoHS Compliant; (6)Qualified to AEC-Q101 Standards for High Reliability.

Diagrams

BAV99-7 dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BAV99-7-F
BAV99-7-F

Diodes Inc.

Diodes (General Purpose, Power, Switching) 75V 350mW

Data Sheet

0-1: $0.21
1-10: $0.14
10-100: $0.04
100-500: $0.03
BAV99-7
BAV99-7

Diodes Inc.

Diodes (General Purpose, Power, Switching) 75V 350mW

Data Sheet

Negotiable
