74FCT16245ATPACTE4

74FCT16245ATPACTE4, 16-bit, transceiver, 64mA, 5V, SSOP-48, 1.0W, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.80~1.89 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 2000 :	1.89 / Piece
2000 ~ 4000 :	1.85 / Piece
4000 ~ 6000 :	1.80 / Piece

PartNumber:: 74FCT16245ATPACTE4

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-14

From Other Seller

Part Number:74FCT16245ATPACTE4
US $1.80 - 1.89
Quantity:

piece

Product Summary

The 74FCT16245ATPACTE4 is a 16-bit transceiver. It is designed for use in bidirectional synchronous communication between two buses, where high speed and low power are required. With the exception of the 74FCT16245ATPACTE4, the device can be operated either as two independent octals or a single 16-bit transceiver. Direction of data flow is controlled by (DIR), the Output Enable (OE) transfers data when LOWand isolates the buses when HIGH. The 74FCT16245ATPACTE4 is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.

Parametrics

74FCT16245ATPACTE4 absolute maximum ratings: (1)Storage Temperature: -55℃ to +125℃; (2)Ambient Temperature with Power Applied: -55℃ to +125℃; (3)DC Input Voltage: –0.5V to +7.0V; (4)DC Output Voltage: –0.5V to +7.0V; (5)DC Output Current(Maximum Sink Current/Pin): –60 to +120 mA; (6)Power Dissipation: 1.0W; (7)Static Discharge Voltage: >2001V.

Features

74FCT16245ATPACTE4 features: (1)Ioff supports partial-power-down mode operation; (2)Edge-rate control circuitry for significantly improved noise characteristics; (3)Typical output skew < 250 ps; (4)ESD > 2000V; (5)TSSOP (19.6-mil pitch) and SSOP (25-mil pitch) packages; (6)Industrial temperature range of -40 to 85℃; (7)VCC = 5V ±10%.
