Product Summary

The 1MBI50L-060 is an IGBT module. It is ideal for chopper application, AC and DC servo drive supply, uninterruptible power supply and industrial machines such as welding machines.

Parametrics

1MBI50L-060 absolute maximum ratings: (1)collecter-emitter voltage: 600V; (2)gare-emitter voltage: ±20V; (3)MAX. power dissipation: 200W; (4)operating temperature: +150℃; (5)storage temperature: -40 to +125℃; (6)isolation voltage: 2500V.

Features

1MBI50L-060 features: (1)low saturation voltage; (2)voltage drive; (3)high speed switching; (4)isolated package.

Diagrams

1MBI50L-060 equilavelent circuit schematic
