Product Summary

The UPC258 is a Bipolar Analog Integrated Circuit.

Parametrics

UPC258 absolute maximum ratings: (1)V＋－V-: -0.3V to +36V; (2)VID: ±30V; (3)VI: V- -0.3V to V+ +0.3V; (4)VO: V- -0.3V to V+ +0.3V; (5)PT: 350mW; (6)TA: -40℃ to +85℃; (7)Tstg: -55℃ to +125℃.

Features

UPC258 features: (1) VIO: ±6.0mV; (2) IIO: ±200nA; (3) IB: 500nA; (4) AV: 20000; (5) Pd: 170mW; (6) CMR: 70dB.

Diagrams

UPC258 block diagram
