TPS7A3001DGNR

TPS7A3001DGNR, -36V, -200mA, Ultralow-Noise, Negative linear regulator, 216mV, MSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2500 ~ 2500 :	2.50 / Piece

PartNumber:: TPS7A3001DGNR

Brand:: Texas Instruments - TI | Pack: MSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-23

From Other Seller

Part Number:TPS7A3001DGNR
US $2.50 - 2.50
Quantity:

piece

Product Summary

The TPS7A3001DGNR is a -36V, -200mA, Ultralow-Noise, Negative linear regulator. The TPS7A3001DGNR includes a CMOS logic-level-compatible enable pin and capacitor-programmable soft-start function that allows for customized power-management schemes. Other features available include built-in current limit and thermal shutdown protection to safeguard the device and system during fault conditions. The applications of the TPS7A3001DGNR include Supply Rails for Op Amps, DACs, ADCs, and Other High-Precision Analog Circuitry, Audio, Post DC/DC Converter Regulation and Ripple Filtering, Test and Measurement, RX, TX, and PA Circuitry, Industrial Instrumention, Base Stations and Telecom Infrastrucure, -12V and -24V Industrial Buses.

Parametrics

TPS7A3001DGNR absolute maximum ratings: (1)IN pin to GND pin: –36 to +0.3 V; (2)OUT pin to GND pin:–33 to +0.3 V; (3)OUT pin to IN pin: –0.3 to +36 V; (4)FB pin to GND pin: –2 to +0.3 V; (5)FB pin to IN pin: –0.3 to +36 V; (6)EN pin to IN pin: –0.3 to +36 V; (7)EN pin to GND pin: –36 to +36 V; (8)NR/SS pin to IN pin: –0.3 to +36 V; (9)NR/SS pin to GND pin:–2 to +0.3 V; (10)Operating virtual junction, TJ: –40 to +125℃; (11)Storage Temperature, Tstg –65 +150℃; (12)Human body model (HBM) 1500V; (13)Electrostatic discharge rating Charged device model (CDM): 500V.
