TPS62350YZGR

TPS62350YZGR, high-frequency, synchronous step-down dc-dc converter, BGA, -0.3V to 7V, 3MHz, 800mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.80~1.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
5000 ~ 5000 :	1.80 / Piece

PartNumber:: TPS62350YZGR

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-25

From Other Seller

Part Number:TPS62350YZGR
US $1.80 - 1.80
Quantity:

piece

Product Summary

The TPS62350YZGR is a high-frequency synchronous step-down dc-dc converter optimized for battery-powered portable applications. Intended for low-power applications, the TPS62350YZGR supports up to 800-mA load current and allows the use of small, low cost inductors and capacitors. The applications of the TPS62350YZGR include SmartReflex Compliant Power Supply, Split Supply DSPs and μP Solutions OMAP, XSCALE, Cell Phones, Smart-Phones, PDAs, Pocket PCs, Digital Cameras, and Micro DC-DC Converter Modules.

Parametrics

TPS62350YZGR absolute maximum ratings: (1)Voltage at AVIN, PVIN(2): -0.3 V to 7 V; (2)Voltage at SW (2): -0.3 V to 7 V; (3)Voltage at EN, VSEL, SCL, SDA, SYNC (2): -0.3 V to 7 V; (4)Voltage at FB(2): -0.3 V to 4.2 V; (5)Power dissipation: Internally limited; (6)TJ Maximum operating junction temperature: 150℃; (7)Tstg Storage temperature range: –65℃ to 150℃; (8)Human body model: 2kV; (9)ESD rating(3) Charge device model: 1kV; (10)Machine model: 200V.

Features

TPS62350YZGR features: (1)88% Efficiency at 3MHz Operation; (2)800mA Output Current at VI = 2.7V; (3)3MHz Fixed Frequency Operation; (4)Best in Class Load and Line Transient; (5)Complete 1mm Component Profile Solution; (6)±2% PWM DC Voltage Accuracy; (7)35-ns Minimum On-Time; (8)Efficiency Optimized Power-Save Mode (Light PFM); (9)Transient Optimized Power-Save Mode (Fast PFM); (10)28μA Typical Quiescent Current; (11)I2C Compatible Interface up to 3.4 Mbps; (12)Pin-Selectable Output Voltage; (13)Synchronizable On the Fly to External Clock Signal; (14)Available in a 10-Pin QFN (3 x 3 mm) and 12-Pin NanoFree (CSP) Packaging.
