SN74HC139QPWRQ1

SN74HC139QPWRQ1, dual 2-line to 4-line decoder/demultiplexer, TSSOP, -0.5V to 7V, 20mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.32~0.32 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 1000 :	0.32 / Piece

PartNumber:: SN74HC139QPWRQ1

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:SN74HC139QPWRQ1
US $0.32 - 0.32
Quantity:

piece

Product Summary

The SN74HC139QPWRQ1 is a dual 2-line to 4-line decoder/demultiplexer designed for high-performance memory-decoding or data-routing applications requiring very short propagation delay times. In high-performance memory systems, the SN74HC139QPWRQ1 can minimize the effects of system decoding. When employed with high-speed memories utilizing a fast enable circuit, the delay time of the SN74HC139QPWRQ1 and the enable time of the memory usually are less than the typical access time of the memory. This means that the effective system delay introduced by the decoders is negligible.

Parametrics

SN74HC139QPWRQ1 absolute maximum ratings: (1)Supply voltage range, VCC: -0.5 V to 7 V; (2)Input clamp current, IIK (VI < 0 or VI > VCC) : ±20 mA; (3)Output clamp current, IOK (VO < 0 or VO > VCC): ±20 mA; (4)Continuous output current, IO (VO = 0 to VCC): ±25 mA; (5)Continuous current through VCC or GND: ±50 mA; (6)Package thermal impedance, θJA: 73℃/W; (7)Storage temperature range, Tstg: -65 to 150℃.

Features

SN74HC139QPWRQ1 features: (1)Targeted Specifically for High-Speed Memory Decoders and Data-Transmission Systems; (2)Wide Operating Voltage Range of 2 V to 6 V; (3)Outputs Can Drive Up To 10 LSTTL Loads; (4)Low Power Consumption, 80-μA Max ICC; (5)Typical tpd = 10 ns; (6)±4-mA Output Drive at 5 V; (7)Low Input Current of 1 μA Max; (8)Incorporate Two Enable Inputs to Simplify Cascading and/or Data Reception.
