Product Summary

The PTV12010WAH is a non-isolated power module. It is a part of a new class of complete dc/dc switching regulator modules from Texas Instruments. The PTV12010WAH combines high performance with double-sided, surface mount construction to give designers the flexibility to power the most complex multiprocessor digital systems using off-the-shelf catalog parts. The applications of the PTV12010WAH include Multivoltage Digital Systems, High-End Computing, Networking, 12V Intermediate Bus Architectures.

Parametrics

PTV12010WAH absolute maximum ratings: (1)V(Track) Track input: –0.3V to VI +0.3V; (2)TA Operating temperature range Over VI range: –40℃ to 85℃; (3)Lead temperature 5 seconds: 260℃; (4)Tstg Storage temperature: –40℃ to 125℃; (5)V(Inhabit) Inhibit (pin 12) input voltage: –0.3V to 7V.

Features

PTV12010WAH features: (1)8 A Output Current; (2)12V Input Voltage; (3) Wide-Output Voltage Adjust (1.2 V to 5.5 V)/(0.8 V to 1.8 V); (4)Efficiencies up to 93%; (5)On/Off Inhibit; (6)Prebias Start Up; (7)Undervoltage Lockout; (8)Auto-Track. Sequencing; (9)Output Over current Protection (Nonlatching, Auto-Reset); (10)Operating Temperature: –40℃ to 85℃; (11)Safety Agency Approvals: UL/cUL 60950, EN60950 VDE (Pending); (12) POLA Alliance Compatible.
