MAX7430EUB

MAX7430EUB, Filter, SOP, +6V, 777mW, Maxim Integrated Products

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.00~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 100 :	6.00 / Piece

PartNumber:: MAX7430EUB

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:MAX7430EUB
US $6.00 - 6.00
Quantity:

piece

Product Summary

The MAX7430EUB is a Filter. It is low-cost, high-performance replacements for standard discrete filter and buffer solutions. The MAX7430EUB is ideal for anti-aliasing and DAC smoothing video applications, when analog video is reconstructed from a digital data stream. The MAX7430EUB requires a single +5V supply and the filters have a cutoff frequency optimized for NTSC, PAL, and standard definition digital TV (SDTV) video signals. The MAX7430EUB features Maxim’s Single Pin Bus (MSPB.) interface to digitally control channel selection (IN_A or IN_B), adjust high-frequency boost, bypass the filter, configure luma vs. chroma operation, and control the output disable. The applications of the MAX7430EUB include Set-Top Boxes, DVD Players, Hard-Disk Recorders, and Camcorders.

Parametrics

MAX7430EUB absolute maximum ratings: (1)VCC to GND: +6V; (2)All Other Pins to GND: -0.3V to (VCC + 0.3V); (3)Maximum Current Into Any Pin: ±50mA; (4)Continuous Power Dissipation (TA = +70℃); (5)8-Pin SOT23 (derate 9.71mW/℃ above +70℃): 777mW; (6)10-Pin μMAX (derate 6.94mW/℃ above +70℃): 555.5mW; (7)14-Pin TSSOP (derate 9.1mW/℃ above +70℃): 727mW; (8)Operating Temperature Range: -40℃ to +85℃; (9)Storage Temperature Range: -65℃ to +150℃; (10)Junction Temperature: +150℃; (11)Lead Temperature (soldering, 10s): +300℃.

Features

MAX7430EUB features: (1)Ideal for CVBS, Y/C (S-Video), and RGB (Y Pb Pr) Outputs for NTSC, PAL, and SDTV; (2)6th-Order Lowpass Filter; (3)Drives Two 150Ω Video Loads; (4)Four Levels of Passband High-Frequency Boost Control; (5)Input 2 to 1 Multiplexer; (6)Output Disable; (7)Filter Bypassing; (8)+5V Single-Supply Voltage; (9)Tiny 8-Pin SOT23 Package (MAX7428), 10-Pin μMAX Package (MAX7430), and 14-Pin TSSOP Package (MAX7432).
