MAX202ECSE+T

MAX202ECSE+T, 15kV, ESD-protected, 5V, RS-232 transceiver, SOP, ±30V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
2500 ~ 2500 :	3.00 / Piece

PartNumber:: MAX202ECSE+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-28

From Other Seller

Part Number:MAX202ECSE+T
US $3.00 - 3.00
Quantity:

piece

Product Summary

The MAX202ECSE+T is a 15kV ESD-protected, 5V RS-232 transceiver. The MAX202ECSE+T line driver/receiver is designed for RS-232 and V.28 communications in harsh environments. Each transmitter output and receiver input is protected against ±15kV electrostatic discharge (ESD) shocks, without latchup. The various combinations of features are outlined in the Selector Guide. The driver and receiver of the MAX202ECSE+T for all ten devices meet all EIA/TIA-232E and CCITT V.28 specifications at data rates up to 120kbps, when loaded in accordance with the EIA/TIA-232E specification.

Parametrics

MAX202ECSE+T absolute maximum ratings: (1)VCC: -0.3V to +6V; (2)V+: (VCC - 0.3V) to +14V; (3)V-: -14V to +0.3V; (4)Input Voltages T_IN: -0.3V to (V+ + 0.3V); (5)R_IN: ±30V; (6)Output Voltages T_OUT: (V- - 0.3V) to (V+ + 0.3V); (7)R_OUT: -0.3V to (VCC + 0.3V); (8)Operating Temperature Ranges: -40℃ to +85℃; (9)Storage Temperature Range: -65℃ to +165℃; (10)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX202ECSE+T features: (1)Low-Voltage. 1μA Supply Current, True +3V to +5.5V RS-232 Transceivers with Auto-Shutdown; (2)Low-Power. ±15kV ESD-Protected Down to 10nA, +3.0V to +5.5V, Up to 1Mbps, True RS-232 Transceivers; (3)Low-Voltage or Data Cable. 15kV ESD-Protected, 1μA, 250kbps, +3.0V/+5.5V, Dual RS-232 Transceivers with Internal Capacitors.
