LMV761MFX

LMv761MFX, precision comparator, SOT, 200V, 5.5V, 300μA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.75~0.75 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
3000 ~ 60000 :	0.75 / Piece

PartNumber:: LMV761MFX

Brand:: National Semiconductor - NS | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-18

From Other Seller

Part Number:LMV761MFX
US $0.75 - 0.75
Quantity:

piece

Product Summary

The LMv761MFX is a precision comparator intended for applications requiring low noise and low input offset voltage. The LMv761MFX single has a shutdown pin that can be used to disable the device and reduce the supply current. The device is available in a space saving SOT23-6 or SOIC-8 package. The applications of the LMv761MFX include Portable and battery-powered systems, Scanners, Set top boxes, High speed differential line receiver, Window comparators, Zero-crossing detectors, High speed sampling circuits.

Parametrics

LMv761MFX absolute maximum ratings: (1)ESD Tolerance, Human Body Model: 2000V; Machine Model: 200V; (2)Supply Voltage (V-–V-): 5.5V; (3)Differential Input Voltage: Supply Voltage; (4)Voltage between any two pins: Supply Voltage; (5)Infrared or Convection (20 sec.): 235℃; (6)Wave Soldering (10 sec.): 260℃ (Lead Temp); (7)Junction Temperature: 150℃; (8)Storage Temperature Range: -65 to 150℃.

Features

LMv761MFX features: (1)Input offset voltage 0.2mV; (2)Input offset voltage (max over temp) 1mV; (3)Input bias current 0.2pA; (4)Propagation delay (OD = 50mV) 120 nsec; (5)Low supply current 300μA; (6)CMRR 100dB; (7)PSRR 110dB; (8)Extended Temperature Range -40 to 125℃; (9)Push-pull output; (10)Ideal for 2.7V and 5V single supply applications; (11)Available in space-saving packages: 6-Pin SOT23 (single w/shutdown), 8-Pin SOIC (single w/shutdown), 8-Pin SOIC/MSOP (dual without shutdown).
