LM324D

LM324D, quad operational amplifier, SOP, 32Vdc, 100nA, ±16V, ON Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.01~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.01~6.00

PartNumber:: LM324D

Brand:: ON Semiconductor - ON | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. elaine's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-07

From Other Seller

Part Number:LM324D
US $0.01 - 6.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM324D is a low–cost, quad operational amplifier with true differential inputs. It has several distinct advantages over standard operational amplifier types in single supply applications. The LM324D can operate at supply voltages as low as 3.0 V or as high as 32 V with quiescent currents about one–fifth of those associated with the MC1741 (on a per amplifier basis). The common mode input range of LM324D includes the negative supply, thereby eliminating the necessity for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.

Parametrics

LM324D absolute maximum ratings: (1)Power Supply Voltages: Single Supply: 32Vdc, Split Supplies VCC, VEE: ±16Vdc; (2)Input Differential Voltage Range: ±32Vdc; (3)Input Common Mode Voltage Range: –0.3 to 32Vdc; (4)Output Short Circuit Duration: Continuous; (5)Junction Temperature: 150 ℃; (6)Storage Temperature Range: –65 to +150 ℃; (7)Operating Ambient Temperature Range: 0 to +70 ℃.

Features

LM324D features: (1)Short Circuited Protected Outputs; (2)True Differential Input Stage; (3)Single Supply Operation: 3.0 V to 32 V (LM224, LM324, LM324A); (4)Low Input Bias Currents: 100nA Maximum (LM324A); (5)Four Amplifiers Per Package; (6)Internally Compensated; (7)Common Mode Range Extends to Negative Supply; (8)Industry Standard Pinouts; (9)ESD Clamps on the Inputs Increase Ruggedness without Affecting Device Operation.
