LM22676MRE-5.0

LM22676MRE-5.0, Step-Down Voltage Regulator, PSOP, 43V, 2kV, National Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 100 :	3.00 / Piece

PartNumber:: LM22676MRE-5.0

Brand:: National Semiconductor - NS | Pack: PSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:LM22676MRE-5.0
US $3.00 - 3.00
Quantity:

piece

Product Summary

The LM22676MRE-5.0 is a Step-Down Voltage Regulator. It is a monolithic integrated circuit which provides all of the active functions for a stepdown (buck) switching regulator capable of driving up to 3A loads with excellent line and load regulation characteristics. High efficiency (>90%) is obtained through the use of a low ON-resistance N-channel MOSFET. The LM22676MRE-5.0 consists of a fixed 5V output and an adjustable version. The LM22676MRE-5.0 provides for an easy to use complete design using a minimum number of external components. The switching clock frequency is provided by an internal fixed frequency oscillator which operates at 500 kHz. The LM22676MRE-5.0 also has built in thermal shutdown, current limiting and an enable control input that can power down the regulator to a low 25μA quiescent current standby condition. The applications of the LM22676MRE-5.0 are: (1)Industrial Control; (2)Telecom and Datacom Systems; (3)Embedded Systems; (4)Automotive Telematics and Body Electronics; (5)Conversions from Standard 24V, 12V and 5V Input Rails.

Parametrics

LM22676MRE-5.0 absolute maximum ratings: (1)VIN to GND: 43V; (2)EN Pin Voltage: -0.5V to 6V; (3)SW to GND: -5V to VIN; (4)BOOT Pin Voltage VSW: + 7V; (5)FB Pin Voltage: -0.5V to 7V; (6)Power Dissipation: Internally Limited; (7)Junction Temperature: 150℃; (8)Soldering Information: 260℃; (9)ESD Rating: ±2 kV; (10)Storage Temperature Range: -65℃ to +150℃.

Features

LM22676MRE-5.0 features: (1)Wide input voltage range: 4.5V to 42V; (2)Internally compensated voltage mode control; (3)Stable with low ESR ceramic capacitors; (4)120 mΩ N-channel MOSFET TO-263 THIN package; (5)100 mΩ N-channel MOSFET PSOP-8 package; (6)Switching frequency of 500 kHz; (7)-40℃ to 125℃ operating junction temperature range; (8)Precision enable pin; (9)Integrated boot diode; (10)Integrated soft-start; (11)Fully WEBENCHR enabled; (12)Step-down and inverting buck-boost applications.
