ICL7650SCPDZ

ICL7650SCPDZ, 2MHz, Super Chopper-Stabilized Amplifier, 10pA, +3.5V to -5V, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.53~2.53 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
500 ~ 1000 :	2.53 / Piece

PartNumber:: ICL7650SCPDZ

Brand:: Intersil Corporation - Intersil | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-18

From Other Seller

Part Number:ICL7650SCPDZ
US $2.53 - 2.53
Quantity:

piece

Product Summary

The ICL7650SCPDZ is a Super Chopper-Stabilized Amplifier. It offers exceptionally low input offset voltage and is extremely stable with respect to time and temperature. The ICL7650SCPDZ is a direct replacement for the industry-standard ICL7650SCPDZ offering improved input offset voltage, lower input offset voltage temperature coefficient, reduced input bias current, and wider common mode voltage range. All improvements are highlighted in bold italics in the Electrical Characteristics section. Critical parameters are guaranteed over the entire commercial temperature range.

Parametrics

ICL7650SCPDZ absolute maximum ratings: (1)Supply Voltage (V+ to V-): 18V; (2)Input Voltage: (V+ +0.3) to (V- -0.3); (3)Voltage on Oscillator Control Pins: V+ to VDuration; (4)of Output Short Circuit: Indefinite; (5)Current to Any Pin: 10mA; (6)While Operating: 100μA.

Features

ICL7650SCPDZ features: (1)Guaranteed Max Input Offset Voltage for All Temperature Ranges; (2)Low Long-Term and Temperature Drifts of Input Offset Voltage; (3)Guaranteed Max Input Bias Current: 10pA; (4)Extremely Wide Common Mode Voltage Range: +3.5V to -5V; (5)Reduced Supply Current: 2mA; (6)Guaranteed Minimum Output Source/Sink Current; (7)Extremely High Gain: 150dB; (8)Extremely High CMRR and PSRR: 140dB; (9)High Slew Rate: 2.5V/μs; (10)Wide Bandwidth: 2MHz; (11)Unity-Gain Compensated; (12)Clamp Circuit to Avoid Overload Recovery Problems and Allow Comparator Use; (13)Extremely Low Chopping Spikes at Input and Output; (14)Improved, Direct Replacement for Industry-Standard ICL7650 and other Second-Source Parts.
