HIN202CBN-T

HIN202CBN-T, RS-232 transmitter/receiver, SOP, ±30V, 5mA, Intersil Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.40~1.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 100 :	1.40 / Piece

PartNumber:: HIN202CBN-T

Brand:: Intersil Corporation - Intersil | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-18

From Other Seller

Part Number:HIN202CBN-T
US $1.40 - 1.40
Quantity:

piece

Product Summary

The HIN202CBN-T is a RS-232 transmitter/receiver interface circuit meets all ElA RS-232E and V.28 specification, and is particularly suited for those applications where ±12V is not available. It requires a single +5V power supply and features onboard charge pump voltage converters which generate +10V and -10V supplies from the 5V supply. The HIN202CBN-T offers a wide variety of RS-232 transmitter/receiver combinations to accommodate various applications (see Selection Table). The drivers feature true TTL/CMOS input compatibility, slew rate-limited output, and 300Ω power-off source impedance. The HIN202CBN-T can handle up to ±30V input, and have a 3kΩ to 7kΩ input impedance. The HIN202CBN also features hysteresis to greatly improve noise rejection.

Parametrics

HIN202CBN-T absolute maximum ratings: (1)VCC to Ground: (GND -0.3V) <VCC < 6V; (2)V+ to Ground: (VCC -0.3V) <V+ < 12V; (3)V- to Ground: -12V < V- < (GND +0.3V); (4)Input Voltages, TIN: (V- -0.3V) < VIN < (V+ +0.3V); RIN: ±30V; (5)Output Voltages, TOUT: (V- -0.3V) < VTXOUT < (V+ +0.3V); ROUT: (GND -0.3V) < VRXOUT < (V+ +0.3V); (6)Short Circuit Duration, TOUT: Continuous; ROUT: Continuous; (7)ESD Classification: Class 1.

Features

HIN202CBN-T features: (1)Meets All RS-232E and V-28 Specifications; (2)HIN203 and HIN205 Require No External Capacitors; (3)Requires Only 0.1μF or Greater External Capacitors; (4)High Data Rate: 120kbit/s; (5)Two Receivers Active in Shutdown Mode (HIN213); (6)Requires Only Single +5V Power Supply; (7)Onboard Voltage Doubler/Inverter; (8)Low Power Consumption (Typ): 5mA; (9)Low Power Shutdown Function (Typ): 1μA; (10)Three-State TTL/CMOS Receiver Outputs.
