Product Summary
The HEF4071BT is a quad 2-input OR gate. The outputs are fully buffered for highest noise immunity and pattern insensitivity to output impedance variations. The HEF4071BT operates over a recommended VDD power supply range of 3 V to 15 V referenced to VSS (usually ground). Unused inputs must be connected to VDD, VSS, or another input.
Parametrics
HEF4071BT absolute maximum ratings: (1)VDD supply voltage: -0.5 to +18V; (2)IIK input clamping current VI＜-0.5V or VI＞VDD + 0.5V: ±10mA; (3)VI input voltage: -0.5 to VDD + 0.5V; (4)IOK output clamping current VO＜ -0.5V or VO＞VDD + 0.5V: ±10mA; (5)II/O input/output current: ±10mA; (6)IDD supply current: 50mA; (7)Tstg storage temperature: -65 to +150℃; (8)Tamb ambient temperature: -40 to +125℃; (9)Ptot total power dissipation Tamb = -40℃ to +125℃; (10)DIP14: 750mW; (11)SO14: 500mW; (12)P power dissipation per output: 100mW.
Features
HEF4071BT features: (1)Fully static operation; (2)5V, 10V, and 15V parametric ratings; (3)Standardized symmetrical output characteristics; (4)Inputs and outputs are protected against electrostatic effects; (5)Specified from -40℃ to +85℃ and -40℃ to +125℃; (6) Complies with JEDEC standard JESD 13-B.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HEF4071BT,652 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUAD 2-IN OR GATE |
Data Sheet |
|
|
||||||||||||
|
HEF4071BT,653 |
NXP Semiconductors |
Gates (AND / NAND / OR / NOR) QUADRUPLE 2-INPUT OR GATE |
Data Sheet |
|
|
||||||||||||
