ADV7521NKBCBZRL-80

High-Definition Multimedia Interface, 20 mA, 80 MHz, 5 V, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.00~6.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	6.00 / Piece
1000 ~ 5000 :	5.50 / Piece
5000 ~ 10000 :	5.00 / Piece

PartNumber:: ADV7521NKBCBZRL-80

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 7/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-07

From Other Seller

Part Number:ADV7521NKBCBZRL-80
US $5.00 - 6.00
Quantity:

piece

Product Summary

The ADV7521NKBCBZRL-80 is an 80 MHz, High-Definition Multimedia Interface (HDMI.) transmitter with consumer electronic control (CEC). It supports HDTV formats up to 720p and 1080i and computer graphic resolutions up to XGA (1024 × 768 @ 75 Hz). With the inclusion of HDCP, the ADV7521NKBCBZRL-80 allows the secure transmission of protected content, as specified by the HDCP 1.3 protocol. The applications of the ADV7521NKBCBZRL-80 include Digital video cameras, Digital still cameras, Personal media players, DVD players and recorders, Digital set-top boxes, A/V receivers, HDMI repeaters/splitters.

Parametrics

ADV7521NKBCBZRL-80 absolute maximum ratings: (1)Digital Inputs: -0.3 V to +5 V; (2)Digital Output Current: 20 mA; (3)Operating Temperature Range: -40℃ to +100℃; (4)Storage Temperature Range: -65 to +150℃; (5)Maximum Junction Temperature: 150℃; (6)Maximum Case Temperature: 150℃.

Features

ADV7521NKBCBZRL-80 features: (1)Low power HDMI/DVI transmitter ideal for portable applications CEC controller and buffer reduce system overhead Incorporates HDMI (v.1.3 with x.v.Color) technology; (2)Compatible with DVI v.1.0 and HDCP 1.3 Single 1.8 V power supply Video/audio inputs accept logic levels from 1.8 V to 3.3 V; (3)80 MHz operation supports all HDTV resolutions from; (4)480i to 1080i Programmable 2-way color space converter Supports RGB, YCbCr, and DDR; (5)Supports ITU656-based embedded syncs Automatic input video format timing detection (CEA-861D); (6)Supports standard S/PDIF for stereo LPCM or compressed; (7)audio up to 192 kHz 8-channel, uncompressed LPCM I2S audio up to 192 kHz; (8)Embedded HDCP keys On-chip MPU with I2C master to perform HDCP operations and EDID reading operations; (9)5 V tolerant I2C and HPD I/Os, no extra device needed; (10)No audio master clock needed for supporting S/PDIF and I2S; (11)On-chip MPU reports HDMI events through interrupts and registers.
