Product Summary

The AD5328BRUZ-REEL7 is a 12-bit buffered voltage output DAC in a 16-lead TSSOP. The AD5328BRUZ-REEL7 operates from a single 2.5V to 5.5V supply, consuming 0.7mA typ at 3V. Its on-chip output amplifiers allow the outputs to swing rail-to-rail with a slew rate of 0.7 V/μs. The AD5328BRUZ-REEL7 uses a versatile 3-wire serial interface that operates at clock rates up to 30 MHz and is compatible with standard SPI, QSPI, MICROWIRE, and DSP interface standards. The applications of the AD5328BRUZ-REEL7 include Portable Battery-Powered Instruments, Digital Gain and Offset Adjustment, Programmable Voltage and Current Sources, Optical Networking, Automatic Test Equipment.

Parametrics

AD5328BRUZ-REEL7 absolute maximum ratings: (1)VDD to GND:–0.3 V to +7 V; (2)Digital Input Voltage to GND:–0.3 V to VDD + 0.3 V; (3)Reference Input Voltage to GND:–0.3 V to VDD + 0.3 V; (4)VOUTA–VOUTD to GND:–0.3 V to VDD + 0.3 V; (5)Operating Temperature Range Industrial (A, B Version): –40℃ to +105℃; (6)Storage Temperature Range:–65℃ to +150℃; (7)Junction Temperature (TJ MAX): 150℃; (8)Power Dissipation: (TJ MAX – TA)/θJA; (9)θJA Thermal Impedance: 150.4℃/W; (10)Reflow Soldering Peak Temperature: 220℃; (11)Time at Peak Temperature: 10 sec to 40 sec.

Features

AD5328BRUZ-REEL7 features: (1)8 Buffered 12-Bit DACs in 16-Lead TSSOP; (2)A Version: ±16 LSB INL, B Version: ±12 LSB INL; (3)Low Power Operation: 0.7mA @ 3V; (4)Guaranteed Monotonic by Design over All Codes; (5)Power-Down to 120nA @ 3V, 400nA @ 5V; (6)Double-Buffered Input Logic; (7)Buffered/Unbuffered/VDD Reference Input Options; (8)Output Range: 0 V to VREF or 0 V to 2 VREF; (9)Power-On Reset to 0 V; (10)Programmability; (11)Individual Channel Power-Down; (12)Simultaneous Update of Outputs (LDAC); (13)Low Power, SPI QSPI MICROWIRE and DSP; (14)Compatible 3-Wire Serial Interface; (15)On-Chip Rail-to-Rail Output Buffer Amplifiers; (16)Temperature Range -40℃ to +105℃.
