Product Summary

The 2SK2225-EQ is a Silicon N Channel MOS FET.

Parametrics

2SK2225-EQ absolute maximum ratings: (1)Drain to source voltage VDSS: 1500 V; (2)Gate to source voltage VGSS: ±20 V; (3)Drain current ID: 2 A; (4)Drain peak current ID(pulse): 7 A; (5)Body–drain diode reverse drain current IDR: 2 A; (6)Channel dissipation Pch: 50 W; (7)Channel temperature Tch: 150 ℃; (8)Storage temperature Tstg –55 to +150 ℃.

Features

2SK2225-EQ features: (1)High breakdown voltage (VDSS = 1500 V); (2)High speed switching; (3)Low drive current; (4)No Secondary Breakdown; (5)Suitable for Switching regulator, DC-DC converter.

Diagrams

2SK2225-EQ block diagram
