Product Summary
The FM50DY-9 is a cost-effective precision CMOS temperature sensor for accurate low-power temperature monitoring applications. Output voltage versus temperature is extremely linear. With no load, the supply current is typically 130μA. For normal operation, the load on VOUT should be 100KΩ or less. In a typical application, a remotely mounted FM50DY-9 is monitored by a microcontroller with an analog A/D converter input. Alternatively, the FM50DY-9 can drive a comparator with a high impedance input. Applications include Mobile Phones, Computers, Battery Management, Office Equipment, HVAC, Power Supply Modules, Disk Drives and Automotive.
Parametrics
FM50DY-9 absolute maximum ratings: (1)Supply Voltage: +7 V; (2)Output Voltage: VDD + 0.5 V; (3)Output Current: 10 μA; (4)Operating Temperature Range: -50 +150℃; (5)Storage Temperature Range: -60 +150℃; (6)Lead Soldering Temperature: 220℃; (7)ESD-Human Body Model: 2000V; (8)ESD-Machine Model: 250V.
Features
FM50DY-9 features: (1)Analog output: 10 mV/℃; (2)Range: -40 to 125℃ range:; (3)Accuracy: ±1℃ at 25℃; (4)Supply Current, 170 μA max. ; (5)Output Drive, 25 μA ; (6)Self-heating < 0.1℃; (7)Operating Voltage: +2.4V to +6V.
Diagrams
