OPA365AIDBVR

OPA365AIDBVR, 50MHz, Low-Distortion, High CMRR, RRI/O, Single-Supply operational amplifier, SOT, 400V, ±10mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10000 ~ 10000 :	1.20 / Piece

PartNumber:: OPA365AIDBVR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-22

From Other Seller

Part Number:OPA365AIDBVR
US $1.20 - 1.20
Quantity:

piece

Product Summary

The OPA365AIDBVR is a 50MHz, Low-Distortion, High CMRR, RRI/O, Single-Supply operational amplifier. It is optimized for very low voltage, single-supply applications. Rail-to-rail input/output, low-noise (4.5nV/√￣Hz) and high-speed operation (50MHz Gain Bandwidth) make the OPA365AIDBVR ideal for driving sampling analog-to-digital converters (ADCs). The OPA365AIDBVR is also well-suited for cell phone power amplifier control loops. The applications of the OPA365AIDBVR include signal conditioning, data acquisition, process control, active filters, test equipment, audio, wideband amplifiers.

Parametrics

OPA365AIDBVR absolute maximum ratings: (1)Supply Voltage: +5.5V; (2)Signal Input Terminals, Voltage(2): (V-) -0.5V to (V+) + 0.5V; (3)Signal Input Terminals, Current(2):±10mA; (4)Output Short-Circuit(3): Continuous; (5)Operating Temperature: -40℃ to +150℃; (6)Storage Temperature: -65℃ to +150℃; (7)Junction Temperature: +150℃; (8)ESD Rating Human Body Model: 4000V; (9)Charged Device Model: 1000V; (10)Machine Model: 400V.

Features

OPA365AIDBVR features: (1)gain bandwidth: 50MHz; (2)zero crossover distortion topology: Excellent THD+N: 0.0004%; (3)CMRR: 100dB (min); (4)Rail-to-Rail Input and Output; (5)Input 100mV Beyond Supply Rail; (6)low noise: 4.5nV/√￣Hz at 100kHz; (7)slew rate: 25V/μs; (8)Fast settling: 0.3μs to 0.01%; (9)Precision: Low Offset: 100μV, Low Input Bias Current: 0.2pA; (10)2.2V to 5.5V operation.
