OPA121KU

OPA121KU, precision monolithic dielectrically isolated FET operational amplifier, SOP, 500mW, 18V, 36V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $12.00~12.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 100 :	12.00 / Piece

PartNumber:: OPA121KU

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-29

From Other Seller

Part Number:OPA121KU
US $12.00 - 12.00
Quantity:

piece

Product Summary

The OPA121KU is a precision monolithic dielectrically isolated FET operational amplifier. Outstanding performance characteristics are now available for low-cost applications. Noise, bias current, voltage offset, drift, open-loop gain, common-mode rejection, and power supply rejection are superior to BIFET amplifiers. The applications of the OPA121KU include optoelectronics, data acquisition, test equipment, medical equipment, radiation hard equipment.

Parametrics

OPA121KU absolute maximum ratings: (1)Supply : ±18VDC; (2)Internal Power Dissipation(1):500mW; (3)Differential Input Voltage: ±36VDC; (4)Input Voltage Range:±18VDC; (5)Storage Temperature Range M package: –65℃ to +150℃; (6)P, U packages:–55℃ to +125℃; (7)Operating Temperature Range M package: –40℃ to +85℃; (8)P, U packages: –25℃ to +85℃; (9)Lead Temperature M, P packages (soldering, 10s): +300℃; (10)U package (soldering, 3s): +260℃; (11)Output Short-Circuit Duration(2): Continuous; (12)Junction Temperature: +175℃.

Features

OPA121KU features: (1)low noise: 6nV/√￣Hz typ at 10kHz; (2)low bias current: 5pA max; (3)low offset: 2mV max; (4)low drift: 3μV/℃ typ; (5)high open-loop gain: 110dB min; (6)high common-mode rejection: 86dB min.
