MSP430F1232IPWR

MSP430F1232IPWR, ultralow-power microcontroller, TSSOP, -0.3V to 4.1V, ±2mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
4000 ~ 4000 :	3.00 / Piece

PartNumber:: MSP430F1232IPWR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-27

From Other Seller

Part Number:MSP430F1232IPWR
US $3.00 - 3.00
MSP430F1232IPWR

US $0.85 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MSP430F1232IPWR is an ultralow-power microcontroller which consists several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low power modes is optimized to achieve extended battery life in portable measurement applications. The MSP430F1232IPWR features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that attribute to maximum code efficiency.

Parametrics

MSP430F1232IPWR absolute maximum ratings: (1)Voltage applied at VCC to VSS: -0.3 V to 4.1 V; (2)Voltage applied to any pin: -0.3 V to VCC + 0.3 V; (3)Diode current at any device terminal: ±2 mA; (4)Storage temperature, Tstg (unprogrammed device): -55℃ to 150℃; (5)Storage temperature, Tstg (programmed device): -40℃ to 85℃.

Features

MSP430F1232IPWR features: (1)Low Supply Voltage Range 1.8 V - 3.6 V; (2)Five Power Saving Modes; (3)Wake-Up From Standby Mode in less than 6 μs; (4)16-Bit RISC Architecture, 125 ns Instruction Cycle Time; (5)Basic Clock Module Configurations: Various Internal Resistors, Single External Resistor, 32-kHz Crystal, High Frequency Crystal, Resonator, External Clock Source; (6)16-Bit Timer_A With Three Capture/Compare Registers; (7)10-Bit, 200-ksps A/D Converter With Internal Reference, Sample-and-Hold, Autoscan, and Data Transfer Controller; (8)Serial Communication Interface (USART0) With Software-Selectable Asynchronous UART or Synchronous SPI (MSP430x12x2 Only).
