Product Summary

The MAX202EESE+ is a ±15kV ESD-Protected, +5V RS-232 Transceiver. The MAX202EESE+ is designed for RS-232 and V.28 communications in harsh environments. Each transmitter output and receiver input is protected against ±15kV electrostatic discharge (ESD) shocks, without latchup. The various combinations of features are outlined in the Selector Guide. The drivers and receivers for all ten devices meet all EIA/TIA-232E and CCITT V.28 specifications at data rates up to 120kbps, when loaded in accordance with the EIA/TIA-232E specification. The applications of the MAX202EESE+ include Notebook, Subnotebook, and Palmtop Computers, Battery-Powered Equipment, Hand-Held Equipment.

Parametrics

MAX202EESE+ absolute maximum ratings: (1)VCC: -0.3V to +6V; (2)V+: (VCC - 0.3V) to +14V; (3)V-: -14V to +0.3V; (4)Input Voltages T_IN: -0.3V to (V+ + 0.3V); (5)R_IN: ±30V; (6)Output Voltages T_OUT: (V- - 0.3V) to (V+ + 0.3V); (7)R_OUT: -0.3V to (VCC + 0.3V); (8)Short-Circuit Duration, T_OUT: Continuous; (9)Continuous Power Dissipation (TA = +70℃): ; (10)16-Pin Plastic DIP (derate 10.53mW/℃ above +70℃): 842mW; (11)16-Pin Narrow SO (derate 8.70mW/℃ above +70℃): 696mW; (12)16-Pin Wide SO (derate 9.52mW/℃ above +70℃): 762mW; (13)16-Pin TSSOP (derate 9.4mW/℃ above +70℃): 755mW; (14)20-Pin Plastic DIP (derate 11.11mW/℃ above +70℃): 889mW; (15)20-Pin SO (derate 10.00mW/℃ above +70℃): 800mW; (16)24-Pin Narrow Plastic DIP (derate 13.33mW/℃ above +70℃): 1.07W; (17)24-Pin Wide Plastic DIP (derate 14.29mW/℃ above +70℃): 1.14W; (18)24-Pin SO (derate 11.76mW/℃ above +70℃): 941mW; (19)24-Pin SSOP (derate 8.00mW/℃ above +70℃): 640mW; (20)28-Pin SO (derate 12.50mW/℃ above +70℃): 1W; (21)28-Pin SSOP (derate 9.52mW/℃ above +70℃): 762mW; (22)Operating Temperature Ranges: 0℃ to +70℃; (23)Storage Temperature Range: -65℃ to +165℃; (24)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX202EESE+ features: (1)For Low-Voltage Applications: MAX3222E/MAX3232E/MAX3237E/MAX3241E/MAX3246E: ±15kV ESD-Protected Down to 10nA, +3.0V to +5.5V, Up to 1Mbps, True RS-232 Transceivers (MAX3246E Available in a UCSP Package); (2)For Low-Power Applications: MAX3221/MAX3223/MAX3243: 1μA Supply Current, True +3V to +5.5V RS-232 Transceivers with Auto-Shutdown; (3)For Space-Constrained Applications MAX3233E/MAX3235E: ±15kV ESD-Protected, 1μA, 250kbps, +3.0V/+5.5V, Dual RS232 Transceivers with Internal Capacitors; (4)For Low-Voltage or Data Cable Applications MAX3380E/MAX3381E: +2.35V to +5.5V, 1μA, 2Tx/2Rx RS-232 Transceivers with ±15kV ESDProtected I/O and Logic Pins.

Diagrams

MAX202EESE+ block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MAX202EESE+
MAX202EESE+

Maxim Integrated Products

RS-232 Interface IC 15kV ESD-Protected 5V RS232 Transceiver

Data Sheet

0-1: $3.76
1-25: $2.52
25-50: $1.82
50-100: $1.80
