LM4040AIM3-4.1/NOPB

LM4040AIM3-4.1/NOPB, precision voltage reference, SOT23, 20mA, 60μA, 306mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.93~0.93 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 1000 :	0.93 / Piece

PartNumber:: LM4040AIM3-4.1/NOPB

Brand:: National Semiconductor - NS | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-21

From Other Seller

Part Number:LM4040AIM3-4.1/NOPB
US $0.93 - 0.93
Quantity:

piece

Product Summary

The LM4040AIM3-4.1/NOPB is a precision voltage reference. It is available in the sub-miniature SC70 and SOT-23 surface-mount package. The LM4040AIM3-4.1/NOPB’s advanced design eliminates the need for an external stabilizing capacitor while ensuring stability with any capacitive load, thus making the LM4040AIM3-4.1/NOPB easy to use. Further reducing design effort is the availability of several fixed reverse breakdown voltages: 2.048V, 2.500V, 3.000V, 4.096V, 5.000V, 8.192V and 10.000V. The minimum operating current increases from 60μA for the LM4040AIM3-4.1/NOPB. Al versions have a maximum operating current of 15 mA. The applications of the LM4040AIM3-4.1/NOPB include Portable, Battery-Powered Equipment, Data Acquisition Systems, Instrumentation, Process Control, Energy Management, Product Testing, Automotive and Precision Audio Components.

Parametrics

LM4040AIM3-4.1/NOPB absolute maximum ratings: (1)Reverse Current: 20 mA; (2)Forward Current: 10 mA; (3)Power Dissipation: 306 mW; (4)Storage Temperature: -65 to +150℃; (5)Lead Temperature: +215℃; (6)Soldering (10 seconds): +260℃; (7)ESD Susceptibility: 2 kV.

Features

LM4040AIM3-4.1/NOPB features: (1) Small packages: SOT-23, TO-92 and SC70; (2) No output capacitor required; (3) Tolerates capacitive loads; (4) Fixed reverse breakdown voltages of 2.048V, 2.500V, 3.000V, 4.096V, 5.000V, 8.192V, and 10.000V.
