Product Summary
The LF347 is a low-cost, high-speed, JFET-input operational amplifier. It requires low supply current yet maintains a large gain-bandwidth product and a fast slew rate. In addition, the matched high-voltage JFET inputs of LF347 provide very low input bias and offset current. The LF347 can be used in applications such as high-speed integrators, digital-to-analog converters, sample-and-hold circuits, and many other circuits. It is characterized for operation from 0℃ to 70℃.
Parametrics
LF347 absolute maximum ratings: (1)Supply voltage, VCC +: 18 V; (2)Supply voltage, VCC –: –18 V; (3)Differential input voltage, VID: ±30 V; (4)Input voltage, VI: ±15 V; (5)Duration of output short circuit: unlimited; (6)Operating temperature range: 0℃ to 70℃; (7)Storage temperature range: –65℃ to 150℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.
Features
LF347 features: (1)Low Input Bias Current: 50 pA Typ; (2)Low Input Noise Current: 0.01 pA/√Hz Typ; (3)Low Total Harmonic Distortion; (4)Low Supply Current: 8 mA Typ; (5)Gain Bandwidth: 3 MHz Typ; (6)High Slew Rate: 13 V/μs Typ; (7)Pin Compatible With the LM348.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LF347 |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||
LF347.B |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||
LF347B |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||
LF347BD |
Texas Instruments |
Operational Amplifiers - Op Amps Gen Pur Biff |
Data Sheet |
|
|
|||||||||||||
LF347BDE4 |
Texas Instruments |
Operational Amplifiers - Op Amps Wide-Bandwidth JFET-Inp Quad |
Data Sheet |
|
|
|||||||||||||
LF347BDG4 |
Texas Instruments |
Operational Amplifiers - Op Amps Wide-BW JFET-input Quad Op Amp |
Data Sheet |
|
|
|||||||||||||
LF347BDR |
Texas Instruments |
Operational Amplifiers - Op Amps Wide-Bandwidth JFET-Inp Quad |
Data Sheet |
|
|
|||||||||||||
LF347BDRE4 |
Texas Instruments |
Operational Amplifiers - Op Amps Wide-Bandwidth JFET-Inp Quad |
Data Sheet |
|
|
