ICL7136CPLZ

Intersil, ICL7136CPLZ, high performance, low power, 3 1/2 digit, A/D converter, DIP, 15V, 70uA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.80~3.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 15 :	3.80 / Piece

PartNumber:: ICL7136CPLZ

Brand:: Intersil Corporation - Intersil | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-18

From Other Seller

Part Number:ICL7136CPLZ
US $3.80 - 3.80
Quantity:

piece

Product Summary

The Intersil ICL7136CPLZ is a high performance, low power 3 1/2 digit, A/D converter. Included are seven segment decoders, display drivers, a reference, and a clock. The ICL7136CPLZ is designed to interface with a liquid crystal display (LCD) and includes a multiplexed backplane drive. The ICL7136CPLZ is an improved version of the ICL7126, eliminating the overrange hangover and hysteresis effects, and should be used in its place in all applications.

Parametrics

ICL7136CPLZ absolute maximum ratings: (1)Supply Voltage ICL7136, V+ to V-: 15V; (2)Analog Input Voltage (Either Input) (Note 1): V+ to V-; (3)Reference Input Voltage (Either Input): V+ to V-; (4)Clock Input ICL7136: TEST to V+; (5)Temperature Range: 0℃ to 70℃.

Features

ICL7136CPLZ features: (1)First Reading Overrange Recovery in One Conversion Period; (2)Guaranteed Zero Reading for 0V Input on All Scales; (3)True Polarity at Zero for Precise Null Detection; (4)1pA Typical Input Current; (5)True Differential Input and Reference, Direct Display Drive; (6)Low Noise - Less Than 15μVP-P; (7)On Chip Clock and Reference; (8)No Additional Active Circuits Required; (9)Low Power - Less Than 1mW; (10)Surface Mount Package Available; (11)Drop-In Replacement for ICL7126, No Changes Needed; (12)Pb-Free Plus Anneal Available (RoHS Compliant).
