Product Summary
The HFBR-4503Z is a Plastic Optical Fiber Cable and Accessory for Versatile Link. The HFBR-4503Z is constructed of a single step-index fiber sheathed in a black polyethylene jacket. The duplex fiber consists of two simplex fibers joined with a zipcord web. The applications of the HFBR-4503Z include Industrial data links for factory automation and plant control, Intra-system links; board-to-board, rack-to-rack, Telecommunications switching systems, Computer-to-peripheral data links, PC bus extension, Proprietary LANs, Digitized video, Medical instruments, Reduction of lightning and voltage transient susceptibility, High voltage isolation.
Parametrics
HFBR-4503Z absolute maximum ratings: (1)Storage and Operating Temperature: -55 to +85 ℃; (2)Recommended Operating Temperature: -40 to +85 ℃; (3)Installation Temperature: -20 to +70 ℃; (4)Short Term Tensile Force: Single Channel: 50 N, Dual Channel: 100 N; (5)Short Term Bend Radius: 25 mm; (6)Long Term Bend Radius: 35 mm; (7)Long Term Tensile Load: 1 N; (8)Flexing: 1000 Cycles.
Features
HFBR-4503Z features: (1)Compatible with Avago Versatile Link family of connectors and fiber optic components; (2)1 mm diameter Plastic Optical Fiber (POF) in two grades: low cost standard POF with 0.22 dB/m typical attenuation, or high performance extra low loss POF with 0.19 dB/m typical attenuation.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HFBR-4503Z |
Avago Technologies |
Fiber Optic Connectors Vers Link Latch Con Grey RoHS |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
HFBR-0310 |
Avago Technologies |
Fiber Optic Development Tools 155 MBd Txcvr Evaluation Kit |
Data Sheet |
Negotiable |
|
||||||||||||
|
HFBR-0310Z |
Avago Technologies |
Fiber Optic Development Tools 125MBd 1300nm Evaluation Kit |
Data Sheet |
|
|
||||||||||||
|
HFBR-0319 |
Avago Technologies |
Fiber Optic Development Tools 1X9 Fiber Optic Evaluation Kit |
Data Sheet |
|
|
||||||||||||
|
HFBR-0400 |
Avago Technologies |
Fiber Optic Development Tools SMA Fiber Optic Evaluation Kit |
Data Sheet |
Negotiable |
|
||||||||||||
|
HFBR-0410 |
Avago Technologies |
Fiber Optic Development Tools ST Fiber Optic Evaluation Kit |
Data Sheet |
Negotiable |
|
||||||||||||
|
HFBR-0410Z |
Avago Technologies |
Fiber Optic Development Tools DC-5MBd 820nm Evaluation Kit |
Data Sheet |
|
|
||||||||||||
