Product Summary
The HEF4066BT is a Quad single-pole single-throw analog switch. The HEF4066BT provides four single-pole, single-throw analog switch functions. Each switch has two input/output terminals (nY and nZ) and an active HIGH enable input (nE). When nE is LOW, the analog switch is turned off. The HEF4066BT is pin compatible with the HEF4016B but exhibits a much lower ON resistance. In addition the ON resistance is relatively constant over the full input signal range. The applications of the HEF4066BT include analog multiplexing and demultiplexing, Digital multiplexing and demultiplexing, Signal gating.
Parametrics
HEF4066BT absolute maximum ratings: (1)VDD supply voltage -0.5 to +18 V; (2)IIK input clamping current VI ＜-0.5 V or VI＞VDD + 0.5V: ±10mA; (3)VI input voltage -0.5 to VDD + 0.5 V; (4)II/O input/output current [1]: ±10mA; (5)Tstg storage temperature: -65 +150℃; (6)Tamb ambient temperature: -40 to +85℃; (7)Ptot total power dissipation Tamb = -40℃ to +85℃; (8)DIP14 [2]: 750mW; (9)SO14 [3]: 500mW; (10)P power dissipation per switch: 100mW.
Features
HEF4066BT features: (1)Fully static operation; (2)5 V, 10 V, and 15 V parametric ratings; (3)Standardized symmetrical output characteristics; (4)Inputs and outputs are protected against electrostatic effects; (5)Specified from -40℃ to +85℃ and -40℃ to +125℃; (6) Complies with JEDEC standard JESD 13-B.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HEF4066BT,652 |
NXP Semiconductors |
Analog Switch ICs QUAD BILATERL SWITCH |
Data Sheet |
|
|
||||||||||||
|
HEF4066BT,653 |
NXP Semiconductors |
Analog Switch ICs QUADRUPLE BILATERAL SWITCHES |
Data Sheet |
|
|
||||||||||||
|
HEF4066BTD |
NXP Semiconductors |
Analog Switch ICs QUAD BILATERL SWITCH |
Data Sheet |
Negotiable |
|
||||||||||||
