Product Summary
The AIC1086-50CM is a low dropout three terminal regulator with 1.5A output current capability. The output voltage is adjustable with the use of a resistor divider or fixed 2.85V, 3.3V, 5V. Dropout is guaranteed at a maximum of 1.5V at maximum output current. Its low dropout voltage and fast transient response make the AIC1086-50CM ideal for low voltage microprocessor applications. Internal current and thermal limiting provides protection against any overload condition that would create excessive junction temperatures. The applications of the AIC1086-50CM include Post Regulator for Switching Supply, Battery Chargers, Constant-Current Regulators, PC Add-On Card.
Parametrics
AIC1086-50CM absolute maximum ratings: (1)VIN pin to ADJ/GND pin: 7V; (2)Operating Junction Temperature Range: 0℃ to 125℃; (3)Storage Temperature Range: - 65℃ to 150℃; (4)Thermal Resistance (Junction to Case) TO-220: 3℃/W; (5)TO-263: 3℃/W; (6)SOT-223: 15℃/W; (7)Lead Temperature (Soldering) 10 sec: 260℃.
Features
AIC1086-50CM features: (1)Dropout Voltage 1.3V at 1.5A Output Current; (2)Fast Transient Response; (3)Line Regulation typically at 0.015%; (4)Load Regulation typically at 0.1%; (5)Internal Thermal and Current Limiting; (6)Adjustable Output Voltage or Fixed 2.85V, 3.3V, 5V; (7)Standard 3-Pin Power Packages.
