QM15TB-2H

QM15TB-2H, transistor module, 1000V, 15A, 150W, Mitsubishi

Rated 5 Rating 5 | reviews | Write a review

Price:: US $38.00~40.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	40.00 / Piece
200 ~ 500 :	39.00 / Piece
500 ~ 800 :	38.00 / Piece

PartNumber:: QM15TB-2H

Brand:: MITSUBISHI - MITSUBISHI | D/C: 11+

Availability:: Supply Ability: 800/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-29

From Other Seller

Part Number:QM15TB-2H
US $38.00 - 40.00
QM15TB-2H

US $19.00 - 21.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The QM15TB-2H is a Mitsubishi transistor module. It is used for Inverters, Servo drives, DC motor controllers, CVCF, NC equipment, Welders.

Parametrics

QM15TB-2H absolute maximum ratings: (1)Collector-emitter voltage: 1000V; (2)Collector-emitter voltage: 1000V; (3)Collector-base voltage: 1000V; (4)Emitter-base voltage: 7V; (5)Collector current: 15A; (6)Collector reverse current: 15A; (7)Collector dissipation: 150W; (8)Base current: 1A; (9)Surge collector reverse current (forward diode current): 150A; (10)Junction temperature: -40 to 150℃; (11)Storage temperature: -40 to 125℃; (12)Isolation voltage: 2500V.

Features

QM15TB-2H features: (1)IC Collector current: 15A; (2)VCEX Collector-emitter voltage: 1000V; (3)hFE DC current gain: 250; (4)Insulated Type; (5)UL Recognized.
