TPS53124RGER

TPS53124RGER, dual, Adaptive on-time DCAP mode synchronous controller, QFN, -0.3V to 32V, 4.5V to 22V, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1000 ~ 1000 :	5.00 / Piece

PartNumber:: TPS53124RGER

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. elaine's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-25

From Other Seller

Part Number:TPS53124RGER
US $5.00 - 5.00
Quantity:

piece

Product Summary

The TPS53124RGER is a dual, Adaptive on-time DCAP mode synchronous controller. The part enables system designers to cost effectively complete the suite of digital TV power bus regulators with the absolute lowest external component count and lowest standby consumption. The main control loop for the TPS53124RGER uses the D-CAP mode that optimized for low ESR output capacitors such as POSCAP or SP-CAP promises fast transient response with no external compensation. The part provides a convenient and efficient operation with conversion voltage from 4.5V to 24V and output voltage from 0.76V to 5.5V. The applications of the TPS53124RGER include Digital TV Power Supply, Networking Home Terminal, and Digital STB.

Parametrics

TPS53124RGER absolute maximum ratings: (1)VIN,EN1,EN2: -0.3 to 26V; (2)VBST1,VBST2: -0.3 to 32V; (3)VBST1,VBST2(wrt LLx): -0.3 to 6V; (4)V5FILT,VFB1,VFB2,TRIP1,TRIP2,VO1,VO2, TEST1,TEST2: -0.3 to 6V; (5)DRVH1, DRVH2: -1 to 32V; (6)DRVH1, DRVH2 (wrt LLx): -0.3 to 6V; (7)LL1,LL2: -2 to 26V; (8)DRVL1,DRVL2,VREG5: -0.3 to 6V; (9)PGND1, PGND2: -0.3 to 0.3V; (10)Operating ambient temperature: -40 to 85℃; (11)Storage Temperature Range, TSTG: -55 to 150℃; (12)Junction Temperature Range, TJ: -40 to 150℃.

Features

TPS53124RGER features: (1)High Efficiency, Low-Power Consumption; (2)D-Cap Mode Enables Fast Transient Response; (3)High Initial Reference Accuracy; (4)Low Output Ripple; (5)Wide Input Voltage Range: 4.5 V to 24 V; (6)Output Voltage Range: 0.76 V to 5.5 V; (7)Low-Side RDS(on) Loss-less Current Sensing; (8)Adaptive Gate Drivers with Integrated Boost Diode; (9)Internal 1.2-ms Voltage-Servo Soft Start; (10)Built-In 5-V Linear Regulator.
