Product Summary
The HEF4046BT is a phase-locked loop circuit that consists of a linear voltage controlled oscillator (VCO) and two different phase comparators with a common signal input amplifier and a common comparator input. A 7 V regulator (zener) diode is provided for supply voltage regulation if necessary. For functional description see further on in this data.
Parametrics
HEF4046BT absolute maximum ratings: (1) Operating supply voltage: 3 to 15V; (2) Power dissipation: 2500μW @ VDD=10V; (3) Maximum operating frequency: 2.0MHz; (4) Linearity: 0.25% @ VDD=10V.
Features
HEF4046BT features: (1)Supply current: 300uA @ VDD=10V; (2)Quiescent device current: 80uA @ Tamb=25℃ VDD=10V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HEF4046BT,652 |
NXP Semiconductors |
Phase Locked Loops (PLL) PHASE LOCKED LOOP |
Data Sheet |
|
|
||||||||||||
|
HEF4046BT,653 |
NXP Semiconductors |
Phase Locked Loops (PLL) PHASE LOCKED LOOP |
Data Sheet |
|
|
||||||||||||
|
HEF4046BTD |
NXP Semiconductors |
Phase Locked Loops (PLL) PHASE LOCKED LOOP W/VCO |
Data Sheet |
